ABB B23 212-100 ‘Bronze’ Two-direction Energy Meter

Product ID:  2CMA100166R1000

Dimensions

• Product Net Width: 70 mm

• Product Net Height: 26.5 mm

• Product Net Depth / Length: 65 mm

• Product Net Weight: 0.32 kg

Container Information

• Package Level 1 Units: 1 piece

• Package Level 1 Width: 100 mm

• Package Level 1 Height: 68 mm

• Package Level 1 Depth / Length: 94 mm

• Package Level 1 Gross Weight: 0.39 kg

• Package Level 1 EAN: 7392696001649

Environmental

• Ambient Air Temperature: Operation -40 … +70 °C

• RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment

Additional Information

• Accuracy: Active Energy Class ±1% (or B for MID meters).

• Communication Interface: Modbus

• Communication: MODBUS RTU / RS485

• Connecting Capacity Main Circuit: 1 … 25 mm²

• Current Rating: 65 A

• Degree of Protection: IP20

• Enclosure Material: Plastic

• Frequency (f): 50/60 Hz

• Function: Electricity meter

• Meter Type: Direct connected

• Mounting Type: DIN rail

• Number of Phases: 3

• Product Main Type: B23

• Product Name: Electricity Meter

• Rated Current (I_n): 65 A

• Rated Voltage (U_r):

  (Un) N-L 220 … 240 V
  (Un) L-L 380 … 415 V

• RoHS Date: 2012-36

• Standards: EN 50470-1

• Sub-Function: Steel
